Panasonic FP0 User Manual

High−speed Counter/Pulse Output/ PWM Output FP0
9 − 4
9.1 Outline of Functions
PWM output function
By using the appropriate instruction, the PWM output function enables a pulse output
of the desired duty ratio.
When you increase the pulse width...
heating
increases.
When you decrease it...
heating
decreases.
9.1.2 Performance of Built−in High−speed Counter
Channel number
There are four channels for the built−in high−speed counter.
The channel number allocated for the high−speed counter will change depending on
the function being used.
Counting range
K−8388608 to K8388607
(HFF8000 to H7FFFFF)
(Coded 24−bit binary)

Panasonic FP0 Specifications

General

Model	FP0
Communication Ports	RS232C, RS485
Power Supply	24V DC
Operating Temperature	0°C to 55°C
Type	Programmable Logic Controller (PLC)
I/O Points	16 to 128
