Panasonic FP0 - Output Specifications

Optional Memory FP0
2 − 16
2.2 Specifications
2.2.4 Output Specifications
2.2.4.1 Relay Output Type
FP0 relay output types: C10RM, C10CRM, C10RS, C10CRS, C14RM, C14CRM,
C14RS, C14CRS
Item Description
Output type Normally open (1 Form A) relay output
Rated control capacity 2 A 250 V AC, 2 A 30 V DC (4.5 A maximum per common)
(at Resistance load)
Output points per
common
C10RM,
C10CRM,
C10RS,
C10CRS
2 points/common +1 point/common +1 point/common
C14RM,
C14CRM,
C14RS,
C14CRS
4 points/common + 1 point/common + 1 point/common
Response time
OFF → ON approx. 10 ms
p
ON → OFF approx. 8 ms
Mechanical life time 20,000,000 operations or more
Electrical life time 100,000 operations or more
Surge absorber None
Operating mode indicator LED
