Panasonic FP0 - Fp0 IO Link Unit; Fp0 Power Supply Unit (Afp)

Specifications
FP0
12 − 14
12.5 Specification: Power Supply Unit I/O Link Unit
12.5 Specification: Power Supply Unit I/O Link Unit
12.5.1 FP0 Power Supply Unit (AFP0634)
Item Specification
Input
Rated operating voltage
100 to 240 V AC
p
Operating voltage range
85 to 264 V AC
Frequency
50/60 Hz
Rated frequency
47 to 63 Hz
phase
Single−phase
Inrush current
30 A (0−p) or less (Cold start)
Leakage current
0.75mA
Holding time
10ms
Output
Rated output
24V ( 5%) DC 0.7A
p
Rated output current
0 to 0.7A
Output ripple
500mV(p−p) or less
Regulation
Over Current Regulation
0.74A
g
Over Voltage Regulation
Available
Life time
20,000h (at 55 C)
12.5.2 FP0 I/O Link Unit
Item Specification
Communication method
Two−line, half−duplex
Synchronous method
A synchronization system
Transmission line
Twisted cables
(Twisted pair cable or VCTF Min. 0.75mm
2
*2C(JIS))
Transmission distance (Total length)
Max. 700m (Twisted pair cable)
Max. 400m (VCTF)
Baud rate
0.5Mbps
Number of I/O points per one I/O
Link unit
64 points
Note)
(Input 32 point + Output 32 point)
I/O map of FP0 I/O Link Unit
32X / 32Y
Interface
RS485
Communication error check method
CRC (Cyclic Redundancy Check)
Note
This number is the number of points that I/O link is available
through the host PLC and the network MEWNET−F.
In the case I/O Link error flag is on (valid), Number of I/O points
are 63 points. (Input 31 points + Output 32 points)
