S−LINK Control UnitFP0
4 − 5
4.2 Specifications
4.2 Specifications
4.2.1 General Specifications
Item Description
Rated operating voltage 24V DC
Operating voltage range 21.6V to 26.4V DC
Rated current consumption 150mA or less
Allowed momentary power off time 10ms at 21.6V, 10ms at 24V
Ambient temperature 0°C to +55°C/32°F to +131°F
Storage temperature −20°C to +70°C/−4°F to +158°F
Ambient humidity 30% to 85% RH (non-condensing)
Storage humidity 30% to 85% RH (non-condensing)
Breakdown voltage 500V AC for 1 minute between S−LINK terminal block and power supply/
ground terminals
Insulation resistance min. 100MΩ (measured with a 500V DC megger)
between S−LINK terminal block and power supply/ground terminals
Vibration resistance 10Hz to 55Hz, 1 cycle/min: double amplitude of 0.75mm/ 0.030in., 10 min on
3 axes
Shock resistance Shock of 98m/s
2
or more, 4 times on 3 axes
Noise immunity 1,000 Vp-p with pulse widths 50ns and 1µs (based on in-house measure-
ments)
Operating condition Free from corrosive gases and excessive dust
