Panasonic FP0 - Page 33

Optional MemoryFP0
2 − 9
2.2 Specifications
Current consumption example
Type Current consumption
FP0 E16RS 100 mA
Type Current consumption
FP0 C14RS 100 mA
FP0 E32T 40 mA
FP0 E16T 25 mA
FP0 E16RS 20 mA
FP Programmer II Ver. 2
C−NET Adapter S2
50 mA
Total current consumption 235 mA or less
FP Programmer II Ver. 2
C14RS E32T E16T E16RS
At power supply connector of
expansion I/O unit FP0 E16RS
At power supply connector of control unit
