InstallationFP0
6 − 11
6.5 Installation Using FP0 Flat Type Mounting Plate
An FP0 unit with an attached FP0 flat type mounting plate can
also be installed sideways on a DIN rail.
DIN rail
FP0 flat type mounting
plate
2
1
