Precautions During Programming FP0
8 − 6
8.2 Handling BCD Data
Output to a 7−segment Display (with Decoder)
Use the BIN−to−BCD conversion instruction “F80 (BCD)”.
PLC
BIN
↓
BCD
(Conversion
using
F80 (BCD)
instruction)
7-segment
display
0 0 0 1 1 0 0 1 1 0 0 1 0 0 1 0
1 9 9 2
0 0 0 0 0 1 1 1 1 1 0 0 1 0 0 0
Data processed in
PLC (BIN data)
Data outputted from
PLC (BCD data)
