Precautions During Programming FP0
8 − 26
8.8 Changing the Set Value of Timer/Counter During RUN
Method 1: Method using the programming tool software
Procedure:
Select “Monitoring Registers” from the Online menu.
Explanation of each column
(1) Displays the line number.
(2) Displays the device code and device number.
(3) Displays the monitored data.
During online monitoring, you can make changes to the data by either pressing [Enter]
in this column or by double clicking.
(4) Displays the base (decimal, hexadecimal, binary or ASCII) and the number of words.
(5) Displays the I/O comment for each register.
You can input I/O comments for each register by either pressing [Enter] in this column or
by double clicking.
Click in each column and change the settings.
For details, please refer to the FPWIN GR help menu.
The “FPWIN GR” tool software has a similar menu.
For information on operating the menus, please check the Help menu.
