Expansion I/O UnitsFP0
3 − 7
3.2 Specifications
3.2.2.1 Limitations on Number of Simultaneous Input ON Points
Keep the number of input points per common which are simultaneously ON within the
following range as determined by the temperature.
Number of
input points
per common
which are
simultaneous
ON
8
at 26.4 V DC
at 24 V DC
Ambient temperature (°C/°F)
6
FP0-E16RS/E16RM
47/
116.6
55/
131
Number of
input points
per common
which are
simultaneous
ON
8
5
4
at 24 V DC
at 26.4 V DC
Ambient temperature (°C/°F)
FP0-E16T/E16P/E8X
34/
93.2
55/
131
43/
109.4
16
9
8
at 24 V DC
at 26.4 V DC
Ambient temperature (°C/°F)
Number of
input points
per common
which are
simultaneous
ON
FP0-E32T/E32P/E16X
26/
78.8
55/
131
34/
93.2
