590 Series DC Digital Drive Routine Maintenance and Repair
8-5
Disposal
This product contains materials which are consignable waste under the Special Waste Regulations 1996 which complies with the EC Hazardous Waste
Directive - Directive 91/689/EEC.
We recommend you dispose of the appropriate materials in accordance with the valid environmental control laws. The following table shows which
materials can be recycled and which have to be disposed of in a special way.
Material Recycle Disposal
metal yes no
plastics material yes no
printed circuit board no yes
The printed circuit board should be disposed of in one of two ways:
1. High temperature incineration (minimum temperature 1200°C) by an incinerator authorised under parts A or B of the Environmental Protection Act
2. Disposal in an engineered land fill site that is licensed to take aluminium electrolytic capacitors. Do not dispose of in a land fill site set aside for
domestic waste.
Packaging
During transport our products are protected by suitable packaging. This is entirely environmentally compatible and should be taken for central disposal
as secondary raw material.
Technical Support Checks
The results of the following checks will be very useful to Parker SSD Drives’ Technical Support.
Caution
Please only attempt these checks if you are electrically competent.
Miscellaneous Checks
9or 8
Check 24V present at Terminals C1 to C9 (C1 is 0V) - dc
Check ±10V present at Terminals B3 and B4 (B1 is 0V) - dc
Check auxiliary supply present at Neutral & Line, 110/240V ac
Check the fans rotate, where applicable
