Parker 591C User Manual

E-6 Technical Specifications 590 Series DC Digital Drive
External AC Supply (RFI) Filters and Line Choke
Filters must only be fitted on the mains side of the contactor.
Always use the recommended external AC Line Choke.
AC supply filter and line choke part numbers for conformance with EN55011 Class A.
Armature Current Rating (A) Total Filter Watt Loss (W) Parker SSD Filter Part No. SSD EMC Line Choke
35
25
1 off CO388965U035 CO463036
70 75 1 off CO388965U110 CO463037
110 75 1 off CO388965U110 CO463038
150, 180 158 1 off CO388965U180 CO463039
270 50 1 off CO467843U340 CO057960
Cabling Requirements for EMC Compliance
Where shielded/armoured cables are specified, use "SY" or "CY" type cables for better performance.
Model Power Supply Cable Motor Cable External Filter to Converter Cable Signal/Control Cable
Cable Type
(for EMC
Compliance)
Unscreened
Screened/
armoured
Replace flying leads with
screened/armoured when >0.6m
Screened
Segregation From all other wiring
(clean)
From all other wiring (noisy) From all other wiring (sensitive)
Length Limitations
With External Filter
Unlimited 50 metres
As short as possible
25 metres
Screen to Earth
Connection
Both ends
Both ends
Converter end only

Parker 591C Specifications

General

Control Modes	Torque, Position
Feedback	Encoder
Communication	RS-485
Operating Temperature	0°C to 55°C
Protection Features	Overcurrent, Overvoltage, Overtemperature
