E-22 Technical Specifications 590 Series DC Digital Drive
Termination Tightening Torque
Product Terminations Maximum Tightening Torque
ALL A1 - A9
B1 - B9
C1 - C9
M2.5 5-7lb.in. 0.56-0.79Nm
M2.5 5-7lb.in. 0.56-0.79Nm
M2.5 5-7lb.in. 0.56-0.79Nm
35 - 270 Amps D1 - D8 M3 4lb.in. 0.45Nm
35 - 180 Amps A+, A-, L1, L2, L3
Ground
M8 8.1lb.ft. 11.0Nm
M6 5.0lb.ft. 6.8Nm
270 Amps A+, A-, L1, L2, L3
Ground
M8 12.2lb.ft. 16.5Nm
M6 5.0lb.ft. 6.8Nm
Mechanical Details
Mounting Orientation Vertical. Refer to Chapter 3: “Installing the Drive" - Mechanical installation for dimensions and air clearances.
590/591
Up to 70A Up to 150A Up to 180A 270A
Nominal Blower
Throughput (m³/hour)
- 100 300 350
Weight (kg (lbs)) 10-14 (22-30) 15 (33.2) 17 (37.5) 20 (44)
Power Terminations Bus bars with M8 screws and captive nuts AC terminals:: bus bars with M8 screws and captive nuts
DC terminals:: M8 bolts with nuts and washers
Control Terminations Plug-on connectors with retaining catches
598/599
Weight (kg (lbs)) 10-14 (22-30)
Power Terminations Bus bars with M8 screws and captive nuts
Control Terminations
Control Board
: Plug on connectors with retaining catches.
Current Feedback/Coding Low Volts:
Screw in with wire protectors.
Coding
High Volts/Armature Feedback
: M5 studs with nuts and washers
