Parker 591C User Manual

590 Series DC Digital Drive Serial Communications
A-23
EI Bisynch Binary Parameter Specification Tables
Block 0
PNO ACCESS DESCRIPTION
0 R/O Instrument Identifier. Same as ASCII mnemonic II.
1 R/W Error report. Same as ASCII mnemonic EE
2 R/O Drive Software Version Number.
Block 1
PNO (ID) (MN) TAG DATA FORMAT LIMITS ACCESS DESCRIPTION
BINARY ASCII BIT ASCII BINARY MIN TO MAX
8 08 063 - 21 xxx.xx R/O Speed Setpoint
9 09 089 - 21 xxx.xx R/O Speed Demand
10 0A 062 - 21 xxx.xx R/O Speed Feedback
11 0B 066 - 21 xxx.xx R/O Current Demand
12 0C 065 - 21 xxx.xx R/O Current Feedback
13 0D 183 - 21 xxx.xx R/O Field Demand
14 0E 181 - 21 xxx.xx R/O Field Feedback
15 0F 115 - 23 xxxxx R/O Health Word
0 0/1 OVERSPEED
1 0/1 MISSING PULSE
2 0/1 FIELD OVER I
3 0/1 Heatsink Over Temperature
4 0/1 Motor Over Temperature
5 0/1 OVER VOLTS (VA)
6 0/1 Speed Feedback
7 0/1 Encoder Failed
8 0/1 Field Failed
9 0/1 Three Phase Failed
10 0/1 Phase Lock Loop
11 0/1 5703 Receive Error
12 0/1 Stall Trip
13 0/1 Over Current Trip
14 0/1 Other Trip
15 0/1
ACCTS Failed
