Service Manual 8 Hydraulic Clamping System
8.1 General
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 44
PERFECTA Schneidemaschinenwerk GmbH D-02625 Bautzen Schäfferstr. 44 Tel.: +49-3591-556-131 to -133 Fax: +49 3591-556-139
8. Hydraulic Clamping System
8.1 General
PERFECTA guillotines have an infinitely variable plunger piston hydraulic system with a
clamping force range adjustable within very wide limits.
For ordering designations of hydraulic components, please refer to the Operating Manual.
Name of the components:
P Gear pump
Z Clamping cylinder (plunger cylinder with fast speed piston)
VD1, VD1.1 Preclamping pressure control valve
VD2 Fast speed pressure control valve
VD3 Safety pressure valve
VDR Preclamping multiway throttle valve
RV1 Non-return valve
SRV Suction valve
STV Stop valve
F Filter
VW1 Proportional pressure valve
VW2 Multiway valve
DR1 Choke screw
D Pressure sensor
Legend to the hydraulic system schematic diagram:
Lines carrying pressurized oil
Lines containing pressureless oil
