Perfecta 115 TS - 8.4.2 Hydraulic Clamping System Settings; 8.4.3 Checking the Settings

Service Manual 8 Hydraulic Clamping System
8.4 Adjusting the hydraulic clamping system
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 53
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
VD2
By VD2 as the acceleration or fast-speed valve, you can readjust the clamp speed
started after you press the cut-release pushbuttons or initiate fully automatic cutting.
The clamp should come down rapidly. For preclamping, it must also allow you to stop
and start it at any height, but should gently touch down on the cutting table. Too high
a clamp speed can result in damage to the machine.
How to adjust:
- Slacken the lock nut.
- Gently readjust the spindle:
• Clockwise = higher speed.
• Anticlockwise = lower speed.
- Tighten the lock nut.
VD3
The VD3 is a safety valve. It is factory-set and must not be readjusted as this will lead
to overloading the clamping system, thus resulting in the breakage of individual com-
ponents.
Compared with the clamping pressure shown in Table 2, this safety valve is set 3 bar
higher.
8.4.2 Hydraulic clamping system settings
Machine size 115 132 168 225
Free circulation Meas. point M1 0.25 - 0.35 0.25 - 0.35 0.25 - 0.35 0.25 - 0.35
VD1, VD1.1 Meas. point M1 1.5 - 1.8 1.5 - 1.8 2.5 3
Max. preclamping force (N)
acc. to prEN 1010
300 300 500 500
VD2 Meas. point M1 2 2 3.8 4.2
min. 0.2 0.2 0.3 0.35
Clamping pressure
(MPa)
max. 12 12 16 20
min. 3 3 3.5 4
Clamping force (kN)
max. 45 45 60 80
Table 2: Hydraulic clamping system settings.
8.4.3 Checking the settings
You can check all pressure stages at measuring point M1 or M2 with the aid of a test
manometer (optional).
For the settings, please refer to Table 2.
