Service Manual 10 Cutting Quality Enhancement Tips
10.1 Trouble occurring/cutting problems and their remedies
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 63
PERFECTA Schneidemaschinenwerk GmbH D-02625 Bautzen Schäfferstr. 44 Tel.: +49-3591-556-131 to -133 Fax: +49 3591-556-139
10.1.2 Overcutting
Overcutting occurs when the lower sheets are longer than the upper ones after cutting.
Figure 44: Overcutting.
Cause Remedy
Dull knife. Replace the knife with a resharpened one.
Wrong cutting edge angle. Soft paper:
Reduce the cutting edge angle,
e. g. from 22° to 20°.
Hard paper:
Increase the cutting edge angle,
e. g. from 22° to 24°.
Excessive clamp pressure:
As the knife is getting deeper into the
paper pile, the increasing density of the
latter causes deflection of the knife.
Reduce the clamp pressure.
The cutting path is not vertical. Correct the cutting path.
Table 6: Causes of and remedies to overcutting.
Knife
Clamp
