Service Manual 10 Cutting Quality Enhancement Tips
10.1 Trouble occurring/cutting problems and their remedies
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 62
PERFECTA Schneidemaschinenwerk GmbH D-02625 Bautzen Schäfferstr. 44 Tel.: +49-3591-556-131 to -133 Fax: +49 3591-556-139
Diagonal shading in the cutting direction of the knife which can be seen and felt as
wavy zones.
Figure 43: Diagonal shading.
Cause Remedy
Knives which were overheated during
resharpening have soft zones which get
dull very quickly.
Resharpen the knife with sufficient coolant
supply. The soft zones must be com-
pletely removed.
Too acute a cutting edge angle causes
swelling at densely printed positions.
Grind a bigger angle (for example, from
22° to 24°).
The knife is too soft. Use a different type of knife (carbide).
Table 5: Causes of and remedies to diagonal shading.
