Perfecta 115 TS - Electrical Equipment; Machine Safety Switches

Service Manual 11 Electrical Equipment
11.1 Machine safety switches
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 66
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
11. Electrical Equipment
11.1 Machine safety switches
1 Q1 - Main switch with EMERGENCY STOP function
2 S50, S51 - Cut release pushbuttons
3 S69 - Clamp lock and cut-inhibit switch
4 S69.1 - Pedal actuating switch
5 B90 - 0…250 bar pressure sensor
6 B81, B82 - Safety latch monitoring proximity switches
Figure 46: Machine front safety switches.
2
3
1
6
4
5
