Perfecta 115 TS - Light Guard for P168;225

Service Manual 12 CEDES Safe 400 Light Guard
12.2 Light guard for P168/225
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 90
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
1 Light guard module 1
2 Status indicator LED (red – light guard is interrupted/green – light guard is free)
3 Light guard module 2
Figure 58: Light guard for P115/132 (transmitter) – right-hand side.
12.2 Light guard for P168/225
1 Light guard module 1
2 Light guard module 2
3 Status indicator LED (red – light guard is interrupted/green – light guard is free)
4 CEDES Safe CIS 3 light guard controller
Figure 59: Light guard for P168/225 (receiver) – left-hand side.
