Service Manual 12 CEDES Safe 400 Light Guard
12.2 Light guard for P168/225
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 91
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
1 Light guard module 1
2 Status indicator LED (rot – light guard is interrupted/green – light guard is free)
3 Light guard module 2
Figure 60: Light guard for P168/225 (transmitter) – right-hand side.
3
1
2
