Service Manual 1 General Instructions
1.1 Installation instructions
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 5
PERFECTA Schneidemaschinenwerk GmbH D-02625 Bautzen Schäfferstr. 44 Tel.: +49-3591-556-131 to -133 Fax: +49 3591-556-139
- The supply voltage at the main connection terminals must coincide with the values
indicated on the machine rating plate.
For a five-wire connection, remove the bridge between PE and N from the main
connection terminal block.
Lead the feeder cable through the opening in the left foot of the machine frame
and then through a union in the inside of the control cabinet.
- Check the motor sense of rotation and change the phases of the power supply
cable if it is not correct. Refer to Chapter 1, "Checking the Motor Direction", in the
Operating Manual.
- Last but not least, make sure the backgauge is square to the table and check the
actual/desired measurement.
When using an AWR option, please note the following:
- Fix the rear table to the cross arm from front, using two additional screws in the
recesses of the table.
- If the machine comes with a lowerable front table compressed air supply will be
required. Connect the air to the AWR control valves in the left machine frame foot.
