Service Manual 11 Electrical Equipment
11.2 Computer control
1/09 PERFECTA 115 / 132 / 168 / 225 – TS 69
PERFECTA Schneidemaschinenwerk GmbH  D-02625 Bautzen  Schäfferstr. 44  Tel.: +49-3591-556-131 to -133  Fax: +49 3591-556-139
Safety module
X501 Safety latch sensor B81/B82
X502 Left-hand cut-release pushbutton S50
X503 Right-hand cut-release pushbutton S51
X504 Knife control cam switches S52, S53, S54
X505 Clamp switch S29
X506.1 Light guard
X506.2 Light guard
X510 Cut/clamp contactors K50/K51 and K60/K61
X511 AWR/special outputs
X512 Power supply/cut feedback/
clamp feedback/safety latch
Control module
X801 Light beam cutting line indicator
X802 Front table light
X803 Power supply/short stroke/front table air bed/rear table air bed/K11
feedback/K10 feedback/pedal switch S69.1
X804 False clamp/false clamp 2
X805 Backgauge sensors B27, B39
X806 Backgauge lock S61
X807 EMERGENCY STOP
X808 Handwheel (track A/track B/pushbutton)
X809 Clamp incremental encoder (reserved)
X810 Servo drive
X811 CAN A
X812 CAN B
X813 Main motor contactors (mains/delta/star)
X814 Pressure sensor (reserved analog input)
X815 Proportional pressure multiway valve (reserved analog output)
X830 Serial interface (reserved)
X831 Serial interface to PC module
