Pulse Width Modulator (PWM) 231 May 03, 2004
Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
*Reset Value refers to the data stored in used bits only. It does not include reserved bits content.
PWMMR5
PWM Match Register 5. MR5 can be enabled through MCR to reset the TC,
stop both the TC and PC, and/or generate an interrupt when it matches the TC.
In addition, a match between MR5 and the TC clears PWM5 in either single-
edge mode or double-edge mode, and sets PWM6 if it is in double-edge mode.
R/W 0 0xE0014044
PWMMR6
PWM Match Register 6. MR6 can be enabled through MCR to reset the TC,
stop both the TC and PC, and/or generate an interrupt when it matches the TC.
In addition, a match between MR6 and the TC clears PWM6 in either single-
edge mode or double-edge mode.
R/W 0 0xE0014048
PWMPCR
PWM Control Register. Enables PWM outputs and selects PWM channel types
as either single edge or double edge controlled.
R/W 0 0xE001404C
PWMLER PWM Latch Enable Register. Enables use of new PWM match values. R/W 0 0xE0014050
Table 166: Pulse Width Modulator Register Map
Name Description Access
Reset
Value*
Address
