BRAKE SYSTEM
Name Torque in Nm
Brake calliper coupling 20 - 24
Front brake disc mounting 11 ÷ 13
Rear brake disc mounting 11 ÷ 13
Front brake calliper mounting on fork 20 ÷ 25
Pipe / brake calliper coupling 20 to 25
Circuit bleed calliper fitting 12 - 16
FRONT SUSPENSION
Name Torque in Nm
Front wheel axle 45 to 50
Holding torque of lower ring nut 20 ÷ 25
Fork stem mounting to the plate 20 ÷ 25
Steering lower ring nut 10 - 13 **
Upper steering ring nut 36 - 39
Stem upper cap 35 - 55
Fixing screw handlebar to steering tube 45 ÷ 50
Pumping element fixing screw 25 - 35
Safety screw on fork leg 6 ÷ 7
Wheel fastening screws 33 - 37
* tighten and loosen completely. ** tighten and loosen by 90°.
REAR SUSPENSION
Name
Torque in Nm
Lock nut 40 ÷ 50
Nut for bolt securing swinging arm to chassis 66 ÷ 73
Central stand retainers 25 ÷ 30
Rear shock-absorber lower retainers 33 ÷ 41
Muffler heat guard retainers 6 - 8
Rear shock absorber upper retainers 33 ÷ 41
Swinging arm to engine retainer, muffler side 66 ÷ 70
swinging arm to engine retainer, transmission side 100 - 120
Side stand clamp 15 ÷ 20
Shock absorber to crankcase bracket fastener 20 - 25
rear shock absorber to muffler support arm bracket fastener 20 - 25
rod retainer 33 - 41
bolt securing swinging arm to chassis 14 ÷ 17
Rear wheel axle 104 ÷ 126
ENGINE ASSEMBLY
Name
Torque in Nm
starter motor retainers 11 - 13
THERMAL UNIT AND TIMING SYSTEM
Name
Torque in Nm
Spark plug 12 ÷ 14
Head fixing stud bolts ***
Head fixing nuts 10 - 12
Exhaust / intake head fixing nuts 10 - 12
Head lubrication control jet 5 - 7
Coolant temperature sensor 10 ÷ 12
counterweight mass fixing screw 7 - 8.5
Tensioner sliding block fixing screw 10 - 14
Rpm timing sensor fixing screw 3 - 4
injector fixing screw 3 ÷ 4
Revolution timing sensor fixing screw 3 ÷ 4
Valve lifter mass stop bell fixing screws 30 - 35
inlet manifold fixing screws 11 - 13
Tappet cover fixing screws 7 - 9
Throttle body fixing screws 11 ÷ 13
camshaft retaining bracket fixing screws 4 - 6
Head fixing screws 10 - 12
Characteristics Beverly 500 i.e.
CHAR - 10
