PIAGGIO Beverly 500 i.e. - Instrument Panel; Front Handlebar Cover; Headlight Assy.

Instrument panel
•
Remove the rear handlebar cover.
•
Unscrew the four screws shown in the
figure to separate the rear handlebar
cover from the instrument unit.
Front handlebar cover
•
Remove the rear handlebar cover.
•
Unscrew the two mounting screws
shown in the figure and remove the
front handlebar cover with headlight.
Headlight assy.
•
Remove the front handlebar cover.
•
Unscrew the three mounting screws
shown in the figure to separate the
headlight from the front handlebar cov-
er.
Beverly 500 i.e. Chassis
CHAS - 313
