PIAGGIO Beverly 500 i.e. - Ignition

Ignition
IGNITION
Specification
Desc./Quantity
1 Instrument panel
2 Electronic control unit
3 Antenna
4 Immobilizer
5 Engine stop remote control switch
6 Main remote control switch
7 Diode 2 A
8 Control unit remote control switch
9 Emergency stop switch
10 Side stand switch
11 Fuse No. 4 (5A)
12 Key switch
13 Main fuse (30A)
14 Battery 12V-12Ah
15 Voltage regulator
16 Flywheel magneto
17 Fuse 5A
18 Fuse No. 2 (10A)
Electrical system Beverly 500 i.e.
ELE SYS - 38
