System sealing check
- Check the proper circuit sealing when it is under
pressure and at the temperature.
- For a more accurate check, wait until the system
has cooled down since small leaks may not be
visible due to evaporation
- The water pump is provided with a drainage hole
in case of leaks from the cooling system mechan-
ical seal, or from the shaft sealing oil guard.
- If coolant or oil leaks are detected, inspect the pump (see Flywheel cover chapter).
N.B.
DO NOT USE OILS OR GREASES WHILE MOUNTING THE COOLING SYSTEM. FAILURE TO OB-
SERVE THIS PRECAUTION WILL IRRETRIEVABLY DEFORM THE SEALING GASKETS.
Coolant replacement
System filling instructions
- Prepare the mixture of 50% water and 50% cool-
ant.
- Fill the system to reach a level ranging between
the MIX and MAX levels indicated in the expansion
tank filler.
- Do not close the expansion tank with the cap.
- Use a transparent hose to connect the venting
union with the expansion tank filler.
- Loosen the vent and start the engine.
- Keep it open until the air has been fully vented.
- Close the bleed screw.
- Stop the engine.
- Restore the level into the expansion tank and tighten the cap.
- Start the engine and let it warm up to reach the electric ventilation temperature.
- Stop the engine.
- Restore the level with cold engine.
