PIAGGIO Beverly 500 i.e. - Battery Recharge and Starting

Specification Desc./Quantity
16 Flywheel magneto
17 Fuse n.7 (15A)
18 Under-saddle compartment light
19 Under-saddle compartment light switch
20 Side/taillights (2 front and 1 rear light) and number plate
light
Battery recharge and starting
START-UP BATTERY RECHARGE
Specification
Desc./Quantity
1 Stop light bulb
2 Starter button
3 Fuse No. 8 (7.5A)
4 Fuse No. 4 (5A)
5 Electronic control unit
6 Engine stop remote control switch
7 Main remote control switch
8 Emergency stop switch
9 Stand switch
10 Flywheel magneto
Electrical system Beverly 500 i.e.
ELE SYS - 40
