PIAGGIO Beverly 500 i.e. - Aesthetic Inspection; Tightening Torques Inspection; Electrical System

Carry out the listed tests before delivering the vehicle.
WARNING
HANDLE FUEL WITH CARE.
Aesthetic inspection
Appearance check:
- Paintwork
- Fitting of plastics
- Scratches
- Dirt
Tightening torques inspection
Lock check
- Safety locks
SAFETY LOCKS:
Name
Torque in Nm
Rear shock absorber retainer to the chassis 38 - 46
Front wheel axle 45 to 50
Rear wheel axle 104 to 126
Rear brake disc mounting 11 ÷ 13
Engine - chassis fixing pin 100 - 120
Fixing screw handlebar to steering tube 45 ÷ 50
Upper steering ring nut 36 - 39
Steering lower ring nut 10 - 13 **
** tighten and loosen by 90°
- Cover retaining screws
Electrical system
Electrical System:
- Main switch
- Headlamps: high beams, low beams, side/taillights (front and rear) and relevant warning lights
- Adjusting the headlights according to the regulations currently in force
- Front and rear stop light buttons and bulb
- Turn indicators and their warning lights
- Instrument lighting
- Instrument panel: fuel and temperature indicator
- Instrument panel warning lights
- Horn
- Electric start-up
- Engine stop by emergency stop switch and side stand
- Saddle electric opening button
Pre-delivery Beverly 500 i.e.
PRE DE - 330
