Removing the ignition key-switch when on *lock*
In "Lock" and "ON" position, the cylinder locking
spring cannot be accessed. Drill the clip as shown
in the figure to eject the lock cylinder.
N.B.
FOR REASSEMBLY FROM THIS POSITION, RELEASE THE
STEERING WHEEL AND SET THE LOCK BODY (INSIDE
AND OUTSIDE PART) TO "OFF". THEN, PROCEED AS DE-
SCRIBED IN PARAGRAPH REMOVAL, LOCK IN OFF PO-
SITION.
See also
Removing the ignition key-switch when on *off*
Taillight assy.
•
Remove the two side bumpers.
•
Remove the two side securing screws
from the light unit shown in the figure.
•
Remove the plastic cover of the rear
trunk rack by removing the two side
screws from the lower side of the rack.
Chassis Beverly 500 i.e.
CHAS - 318
