PIAGGIO Beverly 500 i.e. - License Plate Holder

•
- Remove the two fairing retaining
screws shown in the figure.
CAUTION
THE TWO SCREWS SHOWN IN THE FIGURE HAVE DIF-
FERENT LENGTH.
USE THE SHORTER SCREW FOR SIDE MOUNTING SINCE
THE LONGER ONE WOULD DAMAGE THE UNDER-SAD-
DLE COMPARTMENT INSIDE WALL.
•
Remove the plastic parts of the footrests and the sides.
License plate holder
•
Remove the side panels
•
Remove the side retainers from the li-
cence plate holder tail highlighted in
the figure.
•
Remove the two upper retainers high-
lighted in the figure.
•
Remove the two internal retainers to
the battery compartment.
•
Detach the electrical wiring.
•
Remove the whole licence plate holder
support.
Beverly 500 i.e. Chassis
CHAS - 321
