Side fairings
Remove the saddle.
•
Remove the under-saddle cover by
loosening the mounting screw shown
in the figure.
•
Remove the central cover.
•
Remove the rear light unit.
•
- Remove the rear luggage rack.
•
Remove the three front side mounting
screws shown in the figure.
•
Remove the rear side mounting screw
shown in the figure.
•
Remove the screw shown in the figure.
