PIAGGIO Beverly 500 i.e. - Knee-Guard

•
Remove the expansion tank flap.
•
Remove the fixing screw shown in the
figure.
•
Remove the central cover.
•
Remove the two lower retainers indi-
cated in the figure.
•
Remove the whole front shield.
Knee-guard
•
Remove the front shield.
•
Disengage the fuse holder rubber cap
and loosen the two screws shown in
the figure to remove the fuse holder.
Beverly 500 i.e. Chassis
CHAS - 315
