PIAGGIO Beverly 500 i.e. - Footrest

•
Remove the upper mounting screw
through the special hole on the trunk
rack.
•
Remove the rear light group and disconnect the electric connector.
Footrest
•
Remove the central cover.
•
Remove the six screws shown in the
figure.
•
Remove the three retainers shown in
the figure.
•
Remove the diagnosis socket (RHS footrest only) from the side engine inspection port and
remove the complete footrest.
Beverly 500 i.e. Chassis
CHAS - 319
