PIAGGIO Beverly 500 i.e. - Front Fork; Overhaul

Front fork
Removal
- Remove the front wheel.
- Remove the front mudguard
- Remove the front brake calliper
- Remove the front and rear handlebar covers.
- Remove the pin mounting the handlebar to the
steering tube.
- Remove the handlebar and rest it on the shield
back plate.
Using the special tool, loosen and remove the up-
per ring nut, the spacer washer and the counter-
ring nut.
- Extract the fork.
N.B.
TAKE CARE TO SUPPORT THE FORK SO AS TO PREVENT
IT FROM COMING OFF ABRUPTLY
Specific tooling
020055Y Wrench for steering tube ring nut
Overhaul
Check the spring length
- Check the length "A" of the spring.
Characteristic
Standard spring length:
291.6 mm
Suspensions Beverly 500 i.e.
SUSP - 264
