Check
•
Park the scooter on flat ground and rest
it on the central stand.
•
Unscrew the oil dipstick "A", dry it with
a clean cloth and reinsert it, screwing it
in thoroughly.
•
Pull out the dipstick and check that the
oil level is between the MAX. and MIN.
levels indicated on the dipstick (see fig-
ure); if the level is below the MIN value,
restore the proper amount of oil in the
hub.
•
Screw the oil bar back on, checking
that it is tightly in place.
Replacement
•
Remove the oil filler cap "A".
•
Prepare a suitable container.
•
Remove the oil drainage cap "B" and
let the oil drain out completely.
•
Tighten the drainage cap with its gas-
ket and refill.
•
Remove the oil loading cap
Recommended products
AGIP ROTRA 80W-90 rear hub oil
SAE 80W/90 Oil that exceeds the requirements of
API GL3 specifications
Characteristic
Rear hub oil
Capacity approximately 250 cc
Beverly 500 i.e. Maintenance
MAIN - 23
