PIAGGIO Beverly 500 i.e. - Removing the Wheel Axle Bearings

- Use the special extractor to disassemble the
bearing on the engine chassis of the countershaft.
Specific tooling
001467Y006 Pliers to extract 20 mm bearings
001467Y035 Bearing housing, outside ø 47 mm
- Support the hub cover using the stud bolt set.
- Pull out the bearing using the special tool.
Specific tooling
020476Y Stud bolt set
001467Y006 Pliers to extract 20 mm bearings
001467Y007 Driver for OD 54-mm bearings
Removing the wheel axle bearings
- Take out the clip on the outside of the gearbox
cover.
- Support the hub cover using the stud bolt set.
- Pull out the bearing using the special tool.
Specific tooling
020476Y Stud bolt set
020376Y Adaptor handle
020477Y 37 mm adaptor
020483Y 30-mm guide
Engine Beverly 500 i.e.
ENG - 74
