PIAGGIO Beverly 500 i.e. - Front Mudguard

Front mudguard
•
- Remove the front wheel
•
Remove the retainer «A» from the od-
ometer transmission to the mudguard
and from the fork leg right cover.
•
Remove the retainer «B» from the right
front break pipes.
•
Remove the retainer «C» from the fork
leg left cover.
•
Remove the retainer «D» from the left
front break pipes.
•
Remove the two lower retainers «E»
from the fork leg covers.
•
Remove the three retainers «F».
•
Lower the mudguard and remove the
retainer «G» from the left front break
pipes.
•
Remove the mudguard together with
the plate.
Beverly 500 i.e. Chassis
CHAS - 327
