- Insert the special tool as shown in the figure.
- Insert the retaining band of the two half-rings.
- Using a 19 mm hexagonal spanner, extract the
roller bearing.
Specific tooling
020458Y Puller for lower bearing on steering
tube
Refitting
Reassembly of steering tapered bearing seats
Using the special tool, reassemble the tapered
bearing housings on the head as described below:
- Place a new top housing on the head and a new
bearing seat on the bottom side.
- Insert the screw of the special tool set-up with the
adapters for inserting bearing and seat, into the
steering head, as shown in the figure.
- Using two 24 mm wrenches, tighten the screw to
move the two seats in abutment.
N.B.
Beverly 500 i.e. Suspensions
SUSP - 271
