Remove the locking nut, the washer
and the tie rod buffer.
•
Suitably support the engine using a
jack under the oil sump.
•
Remove the nut of the pin mounting the
swinging arm to the chassis.
•
Remove the lock nut, then using a 15-
mm fork spanner, loosen the pin
mounting the swinging arm to the chas-
sis.
•
Remove the swinging arm from the
chassis and remove the shaped wash-
er.
