Pilz PNOZ s30 User Manual

Operation and diagnostics
Operating Manual PNOZ s30
1001715-EN-19
| 95
Error no. Error message Description Remedy
10242 Stuck at Low Track A or /A A low signal is always
present at track A or /A.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
10243 Stuck at High Track B or /B A high signal is always
present at track B or /B.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
10244 Stuck at Low Track B or /B A low signal is always
present at track B or /B.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
10245 Signal Offset Track A The signal at track A
has a DC offset
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
10246 Signal Offset Track /A The signal at track /A
has a DC offset
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
10247 Signal Offset Track B The signal at track B
has a DC offset
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
10248 Signal Offset Track /B The signal at track /B
has a DC offset
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
