Pilz PNOZ s30 User Manual

Operation and diagnostics
Operating Manual PNOZ s30
1001715-EN-19
| 94
Error no. Error message Description Remedy
2007 fAB / fZ does not fit! The ratio of the AB fre-
quency does not match
the fAB/fZ ratio
} Change fAB/fZ in the menu
} Ensure that there is no broken shear
pin or slippage
} Ensure that both encoders operate
correctly
4010 FL K1K2 of Extens.Device Feedback loop K1-K2
of expansion module
open
} Ensure that the feedback loop is wired
correctly
} Ensure that the expansion module op-
erates correctly
4011 FL K3K4 of Extens.Device Feedback loop K3-K4
of expansion module
open
} Ensure that the feedback loop is wired
correctly
} Ensure that the expansion module op-
erates correctly
4012 Expansion connector is
missing
The terminator on the
expansion interface is
not connected
} Ensure that the appropriate yellow ter-
minator is connected.
} Ensure that the expansion module op-
erates correctly
5000 Input Device undefined! No encoder configured
(delivery condition, de-
fault values)
} Create the encoder configuration in
the "Encoder settings" menu
5003 Pos. or Dir. not with Ini Position monitoring or
direction monitoring
configured, although
"Initiator" is selected as
the encoder
} Do not configure direction or position
monitoring
} Select rotary encoder
6000 "AB frequency deviation" Frequency difference
between proximity
switches A and B
e.g. due to edge jitter at
standstill over an exten-
ded period
} Reset error via a valid signal over the
standstill limit, a falling edge at input
S34 (Start) or via the special function
"Error acknowledgement".
} Ensure that the proximity switches op-
erate correctly
7000 Select Input not 1 v .4 ! A parameter set other
than P1, P2, P4 or P8
is selected in mode "1
from 4".
} Select a longer delay time for the se-
lect inputs in order to filter out invalid
signals resulting from contact bounce
or an intermediate state
10241 Stuck at High Track A or /A A high signal is always
present at track A or /A.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
