Operation and diagnostics
Operating Manual PNOZ s30
1001715-EN-19
| 97
Error no. Error message Description Remedy
10257 Ini npn npn both inactive Both proximity switches
are inactive at the same
time
} Install proximity switches so that one
proximity switch is always activated.
} Ensure that the encoders are con-
figured correctly
} Ensure that the proximity switches op-
erate correctly
} Ensure that the supply voltage is
present at the proximity switches
} Ensure that the proximity switches are
wired correctly
10258 Ini pnp npn both inactive Both proximity switches
are inactive at the same
time
} Install proximity switches so that one
proximity switch is always activated.
} Ensure that the encoders are con-
figured correctly
} Ensure that the proximity switches op-
erate correctly
} Ensure that the supply voltage is
present at the proximity switches
} Ensure that the proximity switches are
wired correctly
10259 Ini npn pnp both inactive Both proximity switches
are inactive at the same
time
} Install proximity switches so that one
proximity switch is always activated.
} Ensure that the encoders are con-
figured correctly
} Ensure that the proximity switches op-
erate correctly
} Ensure that the supply voltage is
present at the proximity switches
} Ensure that the proximity switches are
wired correctly
10260 Ini Signal /A Not permitted Invalid signal at track /A
} Ensure that the encoders are con-
figured correctly
} Ensure that the wiring is correct
10261 Ini Signal /B Not permitted Invalid signal at track /B
} Ensure that the encoders are con-
figured correctly
} Ensure that the wiring is correct
10262 Ini Signal A invalid The signal at track A is
outside the permitted
voltage range
} Ensure that the encoders are con-
figured correctly
} Ensure that the wiring is correct
