Operation and diagnostics
Operating Manual PNOZ s30
1001715-EN-19
| 98
Error no. Error message Description Remedy
10263 Ini Signal B invalid The signal at track B is
outside the permitted
voltage range
} Ensure that the encoders are con-
figured correctly
} Ensure that the wiring is correct
10264 Track S Error wrong voltage The voltage at track S
is outside of the per-
missible range
(e.g. because the en-
coder has detected an
internal error and sig-
nals this via track S)
For calculation of the
measured voltage see
(1)
} Check the encoders' supply voltage
} Ensure that the wiring is correct
} Check configuration of the min. and
max. voltage at track S "Track S
Umax / Umin"
} Ensure that the encoder operates cor-
rectly
10266 Stuck at High Track Z or /Z A high signal is always
present at track Z or /Z.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
10267 Stuck at Low Track Z or /Z A low signal is always
present at track Z or /Z.
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that there is no short circuit in
the wiring
10268 Signal error Track A or B No feasible signal at
the tracks AB
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
} Check supply voltage.
10269 Signal error Track /A or /B No feasible signal at
the tracks /A/B
} Ensure that the encoders are con-
figured correctly
} Ensure that the encoder operates cor-
rectly
} Ensure that the wiring is correct
} Check supply voltage.
31014 System error An error was detected
while monitoring the in-
ternally generated 24 V
voltage.
} Check whether device immediately re-
cognises the error again after a restart
} Device defective, exchange
