Operation and diagnostics
Operating Manual PNOZ s30
1001715-EN-19
| 99
Error no. Error message Description Remedy
31015 System error An error was detected
while monitoring the in-
ternally generated 5 V
voltage.
} Check whether device immediately re-
cognises the error again after a restart
} Device defective, exchange
31016 System error An error was detected
while monitoring the in-
ternally generated 3.3 V
voltage.
} Check whether device immediately re-
cognises the error again after a restart
} Device defective, exchange
31017 System error An error was detected
while monitoring the in-
ternally generated VCC
voltage.
} Check whether device immediately re-
cognises the error again after a restart
} Device defective, exchange
32003 System error A difference was detec-
ted when comparing
the process image of
the outputs with the ad-
jacent channel
} Under Settings/Permanent display,
select no time display
} Note all the additional parameters and
contact Support
32004 System error The fed-back state of
the "Relay Control" root
relay does not corres-
pond to the target state
} Device defective, exchange
32005 System error The fed-back state of
the relay Rel1 does not
correspond to the target
state
} Device defective, exchange
} Use another, functioning relay output
32006 System error The fed-back state of
the relay Rel2 does not
correspond to the target
state
} Device defective, exchange
} Use another, functioning relay output
35043 System error An output for synchron-
ous start was selected
at the same time as an
output assignment that
is not compatible with a
synchronous start.
This can happen when
the configuration of a
PNOZ s30 device ver-
sion <v3.0 was loaded
} Deactivate synchronous start setting
->see Synchronous start [ 25]
} Or, if a synchronous start is neces-
sary
} Deactivate analogue output, as it is
not compatible with a synchronous
start
->see Analogue output [ 27]
} Deactivate error output switch func-
tion on outputs assigned to a syn-
chronous start
->see Switch functions [ 33]
41215 System error The device was
switched to the stop
state. This is a sub-
sequent error that oc-
curs only in combina-
tion with other errors.
For information only
