Planet IGS-10020 Series User Manual

User’s Manual
109
4.3.3 SNMP Trap Configuration
Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-3-2 appears.
Figure 4-3-2: SNMP Trap Configuration page Screenshot
The page includes the following fields:
Object Description
• Trap Config
Indicates which trap Configuration's name for configuring. The allowed string
length is 0 to 255, and the allowed content is ASCII characters from 33 to 126.
• Trap Mode
Indicates the SNMP trap mode operation. Possible modes are:
 Enabled: Enable SNMP trap mode operation.
 Disabled: Disable SNMP trap mode operation.
• Trap Version
Indicates the SNMP trap supported version. Possible versions are:
 SNMP v1: Set SNMP trap supported version 1.
 SNMP v2c: Set SNMP trap supported version 2c.
 SNMP v3: Set SNMP trap supported version 3.
