Planet IGS-10020 Series User Manual

User’s Manual
19
1.5 Product Specifications
IGS-10020MT/IGS-12040MT/IGS-20040MT
Model Name
IGS-10020MT
IGS-12040MT
IGS-20040MT
Hardware Specifications
Copper Ports
8 10/ 100/1000BASE-T
RJ45 Auto-MDI/MDI-X
ports
8 10/ 100/1000BASE-T
RJ45 Auto-MDI/MDI-X
ports
16 10/ 100/1000BASE-T
RJ45 Auto-MDI/MDI-X
ports
SFP/mini-GBIC Slots
2 1000BASE-X SFP
interfaces (Port-9 to
Port-10)
Compatible with
100BASE-FX SFP
4 1000BASE-X SFP
interfaces (Port-9 to
Port-12)
Compatible with
100BASE-FX SFP
4 1000BASE-X SFP
interfaces (Port-17 to
Port-20)
Compatible with
100BASE-FX SFP
Console -
1 x RJ45 serial port
(115200, 8, N, 1)
1 x RJ45 serial port
(115200, 8, N, 1)
Switch Architecture
Store-and-Forward
Switch Fabric
20Gbps/non-blocking
24Gbps/non-blocking
40Gbps/non-blocking
Throughput (packet per second)
14.8Mpps@64Bytes 17.85Mpps@64Bytes 25.6Mpps@64Bytes
Address Table
8K entries, automatic
source address learning
and ageing
8K entries, automatic
source address learning
and ageing
8K entries, automatic
source address learning
and ageing
Shared Data Buffer
512 kilobytes
4Mbits
4Mbits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
9Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
ESD Protection
6KV DC
Enclosure
IP30 aluminum case
Installation
DIN rail kit and wall-mount kit
Connector
Removable 6-pin terminal
block for power input
Pin 1/2 for Power 1; Pin
3/4 for fault alarm; Pin 5/6
for Power 2
Removable 6-pin terminal
block for power input
Pin 1/2 for Power 1; Pin
3/4 for fault alarm; Pin 5/6
for Power 2
Removable 6-pin terminal
block for DI/DO interface
Pin 1/2 for DI 0 & DI 1
; Pin
3/4 for DO 0 & DO 1; Pin
5/6 for GND
Removable 6-pin terminal
block for power input
Pin 1/2 for P
ower 1; Pin 3/4
for fault alarm; Pin 5/6 for
Power 2
Removable 6-pin terminal
block for DI/DO interface
Pin 1/2 for DI 0 & DI 1; Pin
3/4 for DO 0 & DO 1; Pin
5/6 for GND
