User’s Manual
4.5.5 LACP Port Statistics
This page provides an overview for LACP statistics for all ports. The LACP Port Statistics screen in Figure 4-5-7 appears.
Figure 4-5-7: LACP Statistics page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number.
• LACP Received
Shows how many LACP frames have been sent from each port.
• LACP Transmitted
Shows how many LACP frames have been received at each port.
• Discarded
Shows how many unknown or illegal LACP frames have been discarded at each
port.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
: Clears the counters for all ports.
