User’s Manual
4.2.17 Fault Alarm
This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-19
appears.
Figure 4-2-19: Fault Alarm Control Configuration page Screenshot
The page includes the following fields:
Object Description
• Enable
Controls whether Fault Alarm is enabled on this switch.
• Record
Controls whether Record is sending System log or SNMP Trap or both.
• Action
Controls whether Port Fail or Power Fail or both for fault detecting.
• Power Alarm
Controls whether AC, DC1 or DC2 or both for fault detecting.
• Port Alarm
Controls which Ports or all for fault detecting.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
