User’s Manual
• Port
Switch port number.
• Status
Indicates whether specific port is a router port or not.
Buttons
: Click to refresh the page immediately.
: Clears all Statistics counters.
Auto-refresh : Automatic refresh occurs every 3 seconds.
4.8.14 MLD Group Information
Entries in the MLD Group Table are shown on this page. The MLD Group Table is sorted first by VLAN ID, and then by group.
Each page shows up to 99 entries from the MLD Group table, default being 20, selected through the "entries per page" input
field. When first visited, the web page will show the first 20 entries from the beginning of the MLD Group Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the MLD Group Table. The MLD
Groups Information screen in Figure 4-8-17 appears.
Figure 4-8-17: MLD Snooping Groups Information page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
VLAN ID of the group.
• Groups
Group address of the group displayed.
• Port Members
Ports under this group.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
To Next Page
